Assembly: Burt Clothes Rack Double with Drawer and Crate

1. Lay the two uprights on the ground so that the small registration holes are facing up. Align the two pieces.

Burt Clothes Rack

2. Screw the dowels in the top and bottom centre holes.

Burt Clothes Rack

3. Screw in the remaining dowels and dowel ends.

Burt Clothes Rack

4. Place two female connector bolts into both upright registration holes.

Burt Clothes Rack

5. Hold down the drawer assembly and lift the drawer upwards firmly to separate the two parts. Set aside the drawer.

Burt Clothes Rack

6. Place the drawer assembly on top of the uprights, aligning the registration holes over the female connector already in place under the uprights.

Burt Clothes Rack

7. Place the two male connector bolts through the registration holes on the inside of the drawer and fix them into place with an allen key.

Burt Clothes Rack

8. Place two uprights onto the dowels and into the drawer rebates.

Burt Clothes Rack

9. Place both connector bolts into the registration holes and fix them into place with an allen key.

Burt Clothes Rack

10. Connect the remaining lengths of dowel until the uprights are securely in place.

Burt Clothes Rack

11. Place the remaining two uprights onto the dowels.

Burt Clothes Rack

12. Tighten the dowel ends into the dowels until the uprights are securely in place.

Burt Clothes Rack

13. Stand the unit upright.

Optional: Replace the top dowel end with the supplied hanging peg.

Burt Clothes Rack

14. Place drawer onto the drawer runners and push close, you will hear it click.

Burt Clothes Rack

15. Assembly your crate and rest it onto the three base dowels.

Burt Clothes Rack

16. Enjoy your new Burt Clothes Rack!

Burt Clothes Rack
